User Manual

2–80 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Unselected Valve Set-output Values
When the module starts the Clamp Open Slow Profile, it:
• sets its unselected outputs to the values listed below
• ignores the unselected value of the selected output
• uses ramp rates OSC17 - OSC32 to ramp unselected outputs
if then
the module is commanded to start the
Ejector Profile during this OSC Profile
this OSC Profile surrenders control of the
unselected valve that is the selected
Ejector Profile valve
the module is commanded to start this OSC
Profile during the Ejector Profile
the Ejector Profile gives control of all of its
unselected valves to this OSC Profile
Clamp Open Slow and Ejector Profiles are
run concurrently
all outputs that are unselected in both
profiles are controlled by this OSC Profile
Word Description
OSC09 Output #1 Set-output Value during Profile [19]
OSC10 Output #2 Set-output Value during Profile [19]
OSC11 Output #3 Set-output Value during Profile [19]
OSC12 Output #4 Set-output Value during Profile [19]
OSC13 Output #5 Set-output Value during Profile [19]
OSC14 Output #6 Set-output Value during Profile [19]
OSC15 Output #7 Set-output Value during Profile [19]
OSC16 Output #8 Set-output Value during Profile [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
from setpoint to setpoint during the Clamp Open Slow Profile. The
module interprets a ramp rate entry of zero as a step function ramp
(ramp disable).
Word Description
OSC17 Output #1 Acceleration Ramp Rate during Profile [20]
OSC18 Output #2 Acceleration Ramp Rate during Profile [20]
OSC19 Output #3 Acceleration Ramp Rate during Profile [20]
OSC20 Output #4 Acceleration Ramp Rate during Profile [20]
OSC21 Output #5 Acceleration Ramp Rate during Profile [20]
OSC22 Output #6 Acceleration Ramp Rate during Profile [20]
OSC23 Output #7 Acceleration Ramp Rate during Profile [20]
OSC24 Output #8 Acceleration Ramp Rate during Profile [20]
OSC25 Output #1 Deceleration Ramp Rate during Profile [20]
OSC26 Output #2 Deceleration Ramp Rate during Profile [20]
OSC27 Output #3 Deceleration Ramp Rate during Profile [20]
OSC28 Output #4 Deceleration Ramp Rate during Profile [20]
OSC29 Output #5 Deceleration Ramp Rate during Profile [20]
OSC30 Output #6 Deceleration Ramp Rate during Profile [20]
OSC31 Output #7 Deceleration Ramp Rate during Profile [20]
OSC32 Output #8 Deceleration Ramp Rate during Profile [20]
