User Manual

2–74 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Bit-mapped Control Words
Word Bit Description
OPC01 Block ID = 00010101 (Low byte). High byte reserved for the module. Do not use.
OPC02 Open
OPC03 Configuration Selections
Profile Algorithm Selections
B00 = 0 Vel/Pos selected for First Clamp Open Profile
= 1 Press/Pos selected for First Clamp Open Profile
B01 Open
B02 = 0 Vel/Pos selected for Second Clamp Open Profile
= 1 Press/Pos selected for Second Clamp Open Profile
B03 Open
B04 = 0 Vel/Pos selected for Third Clamp Open Profile
= 1 Press/Pos selected for Third Clamp Open Profile
B05 Open
B06 = 0 Vel/Pos selected for Clamp Open Slow Profile
= 1 Press/Pos selected for Clamp Open Slow Profile
B07 Open
B08 First Clamp Open/Second Clamp Open Logical Bridge Selection
= 0 Start Second Clamp Open Profile at End of First Clamp Open Profile
= 1 Stop and Set-output at End of First Clamp Open Profile
if this pause Bit is: then the module:
SET and SYS21-B14 is SET gives output control to the Ejector Profile
RESET and OPC20 > 00000 immediately begins the Second Clamp Open Profile
RESET and OPC20 = 00000 reacts as if it just completed the Second Clamp Open Profile, and
continues operation based on the state of OPC03-B09
B09 Second Clamp Open/Third Clamp Open Logical Bridge Selection
= 0 Start Third Clamp Open Profile at End of Second Clamp Open Profile
= 1 Stop and Set-output at End of Second Clamp Open Profile
The module checks the state of this bit at completion of the Second Clamp Open Profile
to determine what further action to take:
if this pause Bit is: then the module:
SET and SYS21-B14 is RESET sets its outputs to SOC33 - SOC40
SET, and SYS21-B14 is SET gives output control to the Ejector Profile
RESET and OPC29 > 00000 immediately begins the Third Clamp Open Profile
RESET and OPC29 = 00000 reacts as if it just completed the Third Clamp Open Profile, and
continues operation based the state of OPC03-B10
B10 Third Clamp Open/Clamp Open Slow Logical Bridge Selection
= 0 Start Clamp Open Slow Profile at End of Third Clamp Open Profile
= 1 Stop and Set-output at End of Third Clamp Open Profile
The module checks the state of this bit at completion of the Third Clamp Open Profile
to determine what further action to take:
if this pause Bit is: then the module:
SET and SYS21-B14 is RESET sets its outputs to TOC33 - TOC40
SET and SYS21-B14 is SET gives output control to the Ejector Profile
RESET immediately begins the Clamp Open Slow Profile
OPC – Clamp Open
Profile Block
