2–63Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
JGC
Screw Rotate Jog Set-output Values
The module sets its outputs to these values when DYC01-B09 = 1.
Word Description
JGC09 Output #1 Set-output Value for Screw Rotate Jogs [19]
JGC10 Output #2 Set-output Value for Screw Rotate Jogs [19]
JGC11 Output #3 Set-output Value for Screw Rotate Jogs [19]
JGC12 Output #4 Set-output Value for Screw Rotate Jogs [19]
JGC13 Output #5 Set-output Value for Screw Rotate Jogs [19]
JGC14 Output #6 Set-output Value for Screw Rotate Jogs [19]
JGC15 Output #7 Set-output Value for Screw Rotate Jogs [19]
JGC16 Output #8 Set-output Value for Screw Rotate Jogs [19]
Ram (Screw) Forward Jog Set-output Values
The module sets its outputs to these values when DYC01-B10 = 1.
Word Description
JGC17 Output #1 Set-output Value for Ram (Screw) Forward Jogs [19]
JGC18 Output #2 Set-output Value for Ram (Screw) Forward Jogs [19]
JGC19 Output #3 Set-output Value for Ram (Screw) Forward Jogs [19]
JGC20 Output #4 Set-output Value for Ram (Screw) Forward Jogs [19]
JGC21 Output #5 Set-output Value for Ram (Screw) Forward Jogs [19]
JGC22 Output #6 Set-output Value for Ram (Screw) Forward Jogs [19]
JGC23 Output #7 Set-output Value for Ram (Screw) Forward Jogs [19]
JGC24 Output #8 Set-output Value for Ram (Screw) Forward Jogs [19]
Ram (Screw) Reverse Jog Set-output Values
The module sets its outputs to these values when DYC01-B11 = 1.
Word Description
JGC25 Output #1 Set-output Value for Ram (Screw) Reverse Jogs [19]
JGC26 Output #2 Set-output Value for Ram (Screw) Reverse Jogs [19]
JGC27 Output #3 Set-output Value for Ram (Screw) Reverse Jogs [19]
JGC28 Output #4 Set-output Value for Ram (Screw) Reverse Jogs [19]
JGC29 Output #5 Set-output Value for Ram (Screw) Reverse Jogs [19]
JGC30 Output #6 Set-output Value for Ram (Screw) Reverse Jogs [19]
JGC31 Output #7 Set-output Value for Ram (Screw) Reverse Jogs [19]
JGC32 Output #8 Set-output Value for Ram (Screw) Reverse Jogs [19]
Clamp Forward Jog Set-output Values
The module sets its outputs to these values when DYC01-B12 = 1.
Word Description
JGC33 Output #1 Set-output Value for Clamp Forward Jogs [19]
JGC34 Output #2 Set-output Value for Clamp Forward Jogs [19]
JGC35 Output #3 Set-output Value for Clamp Forward Jogs [19]
JGC36 Output #4 Set-output Value for Clamp Forward Jogs [19]
