Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description
IPC37 Segment 8 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC35 until ram
profile execution (screw) position reaches IPC39 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC38 Segment 8 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC35 until ram (screw)
profile execution position reaches IPC39 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 7 for time period IPC40
profile execution (or until transition if sooner)
IPC39 End of Segment 8 Position Setpoint [12]
IPC40 Segment 8 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC38 for this time period (or until transition if sooner) beginning at completion of Segment 7.
IPC41 Segment 9 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC39 until ram
profile execution (screw) position reaches IPC43 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC42 Segment 9 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC39 until ram (screw)
profile execution position reaches IPC43 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 8 for time period IPC44
profile execution (or until transition if sooner)
IPC43 End of Segment 9 Position Setpoint [12]
IPC44 Segment 9 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC42 for this time period (or until transition if sooner) beginning at completion of Segment 8.
IPC45 Segment 10 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC43 until ram
profile execution (screw) position reaches IPC47 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC46 Segment 10 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC43 until ram (screw)
profile execution position reaches IPC47 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 9 for time period IPC48
profile execution (or until transition if sooner)
IPC47 End of Segment 10 Position Setpoint [12]
IPC48 Segment 10 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC46 for this time period (or until transition if sooner) beginning at completion of Segment 9.
IPC49 Segment 11 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC47 until transition
profile execution
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
