User Manual

2–59Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
IPC
Word Description
IPC22 Segment 4 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC19 until ram (screw)
profile execution position reaches IPC23 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 3 for time period IPC24
profile execution (or until transition if sooner)
IPC23 End of Segment 4 Position Setpoint [12]
IPC24 Segment 4 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC22 for this time period (or until transition if sooner) beginning at completion of Segment 3.
IPC25 Segment 5 Velocity Setpoint [05] or [06]
Segment 4 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC23 until ram
profile execution (screw) position reaches IPC27 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC26 Segment 5 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC23 until ram (screw)
profile execution position reaches IPC27 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 4 for time period IPC28
profile execution (or until transition if sooner)
IPC27 End of Segment 5 Position Setpoint [12]
IPC28 Segment 5 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC26 for this time period (or until transition if sooner) beginning at completion of Segment 4.
IPC29 Segment 6 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC27 until ram
profile execution (screw) position reaches IPC31 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC30 Segment 6 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC27 until ram (screw)
profile execution position reaches IPC31 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 5 for time period IPC32
profile execution (or until transition if sooner)
IPC31 End of Segment 6 Position Setpoint [12]
IPC32 Segment 6 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC30 for this time period (or until transition if sooner) beginning at completion of Segment 5.
IPC33 Segment 7 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC31 until ram
profile execution (screw) position reaches IPC35 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC34 Segment 7 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC31 until ram (screw)
profile execution position reaches IPC35 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 6 for time period IPC36
profile execution (or until transition if sooner)
IPC35 End of Segment 7 Position Setpoint [12]
IPC36 Segment 7 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC34 for this time period (or until transition if sooner) beginning at completion of Segment 6.
