User Manual

2–58 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Injection Profile Setpoints
Word Description
IPC09 Segment 1 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint after starting the Injection Profile until ram
profile execution (screw) position reaches IPC11 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC10 Segment 1 Pressure Setpoint [01]
if: then the module:
If you select Press/Pos controls ram (screw) pressure to this setpoint after starting the Injection Profile until ram (screw)
profile execution position reaches IPC11 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint after starting the Injection Profile for time period
profile execution IPC12 (or until transition if sooner)
IPC11 End of Segment 1 Position Setpoint [12]
IPC12 Segment 1 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to the setpoint
IPC10 for this time period (or until transition if sooner) after starting the Injection Profile.
IPC13 Segment 2 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC11 until ram
profile execution (screw) position reaches IPC15 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC14 Segment 2 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC11 until ram (screw)
profile execution position reaches IPC15 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 1 for time period IPC16
profile execution period IPC16 (or until transition if sooner)
IPC15 End of Segment 2 Position Setpoint [12]
IPC16 Segment 2 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint
IPC14 for this time period (or until transition if sooner) beginning at completion of Segment 1.
IPC17 Segment 3 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC15 until ram
profile execution (screw) position reaches IPC19 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
IPC18 Segment 3 Pressure Setpoint [01]
if: then the module:
you select Press/Pos controls ram (screw) pressure to this setpoint from ram (screw) position IPC15 until ram (screw)
profile execution position reaches IPC19 (or until transition if sooner)
you select Press/Time controls ram (screw) pressure to this setpoint at completion of Segment 2 for time period IPC20
profile execution (or until transition if sooner)
IPC19 End of Segment 3 Position Setpoint [12]
IPC20 Segment 3 Time Setpoint [21] If you select Press/Time profile execution, the module controls ram (screw) pressure to setpoint IPC18
for this time period (or until transition if sooner) beginning at completion of Segment 2.
IPC21 Segment 4 Velocity Setpoint [05] or [06]
if: then the module:
you select Vel/Pos controls ram (screw) forward speed to this setpoint from ram (screw) position IPC19 until ram
profile execution (screw) position reaches IPC23 (or until transition if sooner)
IPC03-B14 is RESET reads this parameter in percent velocity
IPC03-B14 is SET reads it in in.(mm)/s
