2–57Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
IPC
Word Bit Description
B01 = 0 Vel/Pos (limited) Injection Profiles Closed Loop
= 1 Vel/Pos (limited) Injection Profiles Open Loop
B02 = 0 Press/Pos Injection Profiles Closed Loop
= 1 Press/Pos Injection Profiles Open Loop
B03 = 0 Press/Time Injection Profiles Closed Loop
= 1 Press/Time Injection Profiles Open Loop
Selections to Inhibit Closed Loop Up To Shot Size
B04 = 0 Allow Closed Loop Vel/Pos During Entire Profile
= 1 Inhibit Closed Loop Vel/Pos Until 100% Shot Size
if: then the module:
SET when IPC04-B00 is SET inhibits closed-loop control of all Vel/Pos Injection Profiles until ram
(screw) position equals or is less than the 100% shot size position
RESET when IPC04-B00 is SET performs closed-loop control of the entire Vel/Pos Injection Profile.
If IPC04-B00 is RESET ignores the state of this bit.
B05 = 0 Allow Closed Loop LimVel/Pos During
= 1 Inhibit Closed Loop LimVel/Pos Until 100%
if: then the module:
SET when IPC04-B01 is SET inhibits closed-loop control of all LimVel/Pos Injection Profiles until ram
(screw) position equals or is less than the 100% shot size position
RESET when IPC04-B01 is SET performs closed-loop control of the entire LimVel/Pos Injection Profile
IPC04-B01 is RESET ignores the state of this bit
B06 = 0 Allow Closed Loop Press/Pos During Entire Profile
= 1 Inhibit Closed Loop Press/Pos Until 100% Shot Size
if: then the module:
SET when IPC04-B02 is SET inhibits closed-loop control of all Press/Pos Injection Profiles until ram
(screw) position equals or is less than the 100% shot size position
RESET when IPC04-B02 is SET performs closed-loop control of the entire Press/Pos Injection Profile
IPC04-B02 is RESET ignores the state of this bit
B07 = 0 Allow Closed Loop Press/Time During Entire Profile
= 1 Inhibit Closed Loop Press/Time Until 100% Shot Size
if: then the module:
SET when IPC04-B03 is SET inhibits closed-loop control of all Press/Time Injection Profiles until ram
(screw) positionequals or is less than the 100% shot size position
RESET when IPC04-B03 is SET performs closed-loop control of the entire Press/Time Injection Profile
IPC04-B03 is RESET ignores the state of this bit
ERC Enabled/Disabled Selection
B08 = 0 Vel/Pos ERC On
= 1 Vel/Pos ERC Off
B09 = 0 Vel/Pos (limited) ERC On
= 1 Vel/Pos (limited) ERC Off
B10 = 0 Press/Pos ERC On
= 1 Press/Pos ERC Off
B11 = 0 Press/Time ERC On
= 1 Press/Time ERC Off
B12-B15 Open
IPC05 - 08 Open
