User Manual

2–38 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
if then
the module is commanded to start any of
the four Clamp Open Profiles during an
Ejector Profile retract stroke
the Ejector Profile gives control of all of its
unselected valves to the executing Clamp
Open Profile
the module is commanded to start an
Ejector Profile retract stroke during any of
the four Clamp Open Profiles
the executing Clamp Open Profile
surrenders control of only the selected
Ejector Profile retract valve
one of the four Clamp Open Profiles and an
Ejector Profile retract stroke are run
concurrently
all outputs that are unselected in both
profiles are controlled by the executing
Clamp Open Profile
Word Description
ERC09 Output #1 Set-output Value during Retract [19]
ERC10 Output #2 Set-output Value during Retract [19]
ERC11 Output #3 Set-output Value during Retract [19]
ERC12 Output #4 Set-output Value during Retract [19]
ERC13 Output #5 Set-output Value during Retract [19]
ERC14 Output #6 Set-output Value during Retract [19]
ERC15 Output #7 Set-output Value during Retract [19]
ERC16 Output #8 Set-output Value during Retract [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
from setpoint to setpoint during any Ejector Profile retract stroke not
being executed concurrently with one of the four Clamp Open Profiles.
If the module is executing an Ejector Profile retract stroke
concurrently with one of the four Clamp Open Profiles, the module
will access only the two ramp rates in ERC17 - ERC32 that pertain
to the selected Ejector Profile retract valve. The module interprets a
zero ramp rate entry as a step function ramp (ramp disable).
Word Description
ERC17 Output #1 Acceleration Ramp Rate during Retract [20]
ERC18 Output #2 Acceleration Ramp Rate during Retract [20]
ERC19 Output #3 Acceleration Ramp Rate during Retract [20]
ERC20 Output #4 Acceleration Ramp Rate during Retract [20]
ERC21 Output #5 Acceleration Ramp Rate during Retract [20]
ERC22 Output #6 Acceleration Ramp Rate during Retract [20]
ERC23 Output #7 Acceleration Ramp Rate during Retract [20]
ERC24 Output #8 Acceleration Ramp Rate during Retract [20]
ERC25 Output #1 Deceleration Ramp Rate during Retract [20]
ERC26 Output #2 Deceleration Ramp Rate during Retract [20]
ERC27 Output #3 Deceleration Ramp Rate during Retract [20]
ERC28 Output #4 Deceleration Ramp Rate during Retract [20]
