2–34 Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Ejector Full Retract Profile Setpoints
Word Description
EPC33 Full Retract Segment 1 Velocity Setpoint [09] or [10]
if: then the module:
you select Vel/Pos profile execution controls ejector retract speed to this setpoint after starting any full retract portion of the
Ejector Profile until ejector position reaches the larger of EPC35 or EPC60
EPC03-B14 is RESET reads this parameter in percent velocity
EPC03-B14 is SET reads it in in.(mm)/s
EPC34 Full Retract Segment 1 Pressure Setpoint [03]
if: then the module:
you select Press/Pos profile execution controls ejector retract pressure to this setpoint after starting any full retract portion of
the Ejector Profile until ejector position reaches the larger of EPC35 or EPC60
EPC35 End of Full Retract Segment 1 Position Setpoint [16]
EPC36 Full Retract Segment 2 Velocity Setpoint [09] or [10]
if: then the module:
you select Vel/Pos profile execution controls ejector retract speed to this setpoint during any full retract portion of the
Ejector Profile from the ejector position EPC35 until ejector position reaches the larger
of EPC38 or EPC60
EPC03-B14 is RESET reads this parameter in percent velocity
EPC03-B14 is SET reads it in in.(mm)/s
EPC37 Full Retract Segment 2 Pressure Setpoint [03]
if: then the module:
you select Press/Pos profile execution controls ejector retract pressure to this setpoint during any full retract portion of the
Ejector Profile from the ejector position EPC35 until ejector position reaches the larger
of EPC38 or EPC60
EPC38 End of Full Retract Segment 2 Position Setpoint [16]
EPC39 Full Retract Segment 3 Velocity Setpoint [09] or [10]
if: then the module:
you select Vel/Pos profile execution controls ejector retract speed to this setpoint during any full retract
Ejector Profile from the ejector position EPC38 until ejector
position reaches EPC60
EPC03-B14 is RESET reads this parameter in percent velocity
EPC03-B14 is SET reads it in in.(mm)/s
EPC40 Full Retract Segment 3 Pressure Setpoint [03]
if: then the module:
you select Press/Pos profile execution controls ejector retract pressure to this setpoint during any full retract portion of the
Ejector Profile from the ejector position EPC38 until ejector position reaches EPC60
EPC41 -56 Reserved
