Installation Instructions Manual

AC (120/220V) 16A Power Supply 7
$#  &   ! 
3. Slide the power supply onto the left side of the chassis:
&
# "  """
Slide power supply down.
Place keyhole slot over
large screw on I/O chassis.
Make sure mounting brackets
are behind the small screws.

4. Tighten the small screws until snug, plus 1/4 turn (about 29
pound–inches), to secure the power supply to the I/O chassis.
&
# "  """
&
" "!%"
