Installation Instructions Manual

AC (120/220V) 16A Power Supply10
      
!
WARNING
If you connect or disconnect the power supply
cable with power applied an electrical arc can
occur. This could cause an explosion in hazardous
location installations. Be sure power is removed
or the area is nonhazardous before proceeding.
3. Connect the other end of the power cable to the D-shell connector
on the I/O chassis and tighten the connector screws until snug,
plus 1/4 turn.
        

 

 
 
 
