Compact™ 240V ac Input Module
Publication 1769-IN011B-EN-P
Wire Size and Terminal Screw Torque
Each terminal accepts up to two wires with the following restrictions:
I/O Memory Mapping
Input Data File
For each input module, slot x, word 0 in the input data file contains the current
state of the field input points. For the 1769-IM12, bits 12 to 15 are not used.
r= read
Spare/Replacement Module Parts
• Terminal Block: 1769-RTBN18 (1 per kit)
• Door Label: 1769-RL1 (2 per kit)
• Door: 1769-RD (2 per kit)
Wire Type Wire Size
Terminal Screw
Torque
Retaining Screw
Torque
Solid Cu-90°C (194°F) #14 to #22 AWG 0.68 Nm (6 in-lbs) 0.46 Nm (4.1 in-lbs)
Stranded Cu-90°C (194°F) #16 to #22 AWG 0.68 Nm (6 in-lbs) 0.46 Nm (4.1 in-lbs)
Word
Bit Position
1514131211109876543210
0
0 0 0 0rrrrrrrrrrrr
