MicroLogix 1200 Thermocouple/mV Input Module 3
Publication 1762-IN013B-EN-P - June 2013
Description
Item Description Item Description
1a upper panel mounting tab 5 bus connector cover
1b lower panel mounting tab 6 flat ribbon cable with bus connector (female)
2 power diagnostic LED 7 terminal block
3 module door with terminal identification
label
8 DIN rail latch
4 bus connector with male pins 9 pull loop
1a
1b
2
6
8
1a
1b
5
2
3
9
4
6
7
