To Select
Make these bit settings
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Filter Frequency
10 Hz
Not Used
(1)
(1) An attempt to write any non-valid (spare) bit configuration into any selection field results in a module configuration error.
1 1 0
60 Hz 0 0 0
50 Hz 0 0 1
250Hz 0 1 1
500 Hz 1 0 0
1 kHz 1 0 1
Open Circuit
Upscale 0 0
Downscale 0 1
Hold Last State 1 0
Zero 1 1
Temperature Units
Degrees C 0
Degrees F 1
Input Type
Thermocouple J 0 0 0 0
Thermocouple K 0 0 0 1
Thermocouple T 0 0 1 0
Thermocouple E 0 0 1 1
Thermocouple R 0 1 0 0
Thermocouple S 0 1 0 1
Thermocouple B 0 1 1 0
Thermocouple N 0 1 1 1
Thermocouple C 1 0 0 0
-50…50 mV 1 0 0 1
-100…100 mV 1 0 1 0
Data Format
Raw/Proportional 0 0 0
Engineering Units 0 0 1
Engineering UnitsX10 1 0 0
Scaled-for-PID 0 1 0
Percent Range 0 1 1
Enable
Channel
Disable 0
Enable 1
TIP
Program defaults are indicated by zero (0) values. For example, type J
thermocouple is the default (no user intervention) thermocouple type.
