B-2 Troubleshoot the 1756-DH485 Module

If the alphanumeric indicator on the 1756-DH485 module does not cycle

through these messages when you apply power, refer to the following table and

to the troubleshooting section that follows.

Power Cycle Indicators

Interpret the LED Status

Indicators

The LED status indicators on the module provide information about your

module and the status of each channel. The following tables outline the

indicator condition and the corresponding status, and explain what each

condition means.

Interpret the LED Status Indicators

If the POWER

Indicator is

Power Supply

Status is

Recommended Action

Off Not operating. Turn power ON.

Check power wiring connections.

Check fuse.

On Operating. None, normal operation.

Module OK

Indicator

Module Status Recommended Action

Off Not operating. Apply chassis power.

Verify module is completely inserted into

chassis and backplane.

Green flashing Operating but not

routing messages.

None, if no messages are actively being

routed through the module.

To route messages, configure module with

RSLinx software.

Solid Red, then Off Performing self-test. None, normal operation.

Solid Green Operating and routing

messages.

Verify module configuration.

Solid Red In major fault. Reboot module. If red reoccurs, then

replace module.

Red flashing In major fault or

configuration fault.

Check alphanumeric indicator and take

action described in the Alphanumeric

Display Descriptions table.
