Publication 1756-UM532A-EN-P - May 2006
10-4 Communicate from a Logix Controller to an SLC 5/03 Controller over EtherNet/IP and DH-485 Networks
Configure the Message
This dialog shows example values on the Configuration tab for the remote
message.
Message Type: SLC Typed Write
Source Element: interger_slc_dh485[20]
Make sure yo u specify the starting array
element, fo r exa m ple [20].
Number of Elements: 1
Destination Elem en t : N7:2 0
