Chapter
10
Communicate from a Logix Controller to an
SLC 5/03 Controller over EtherNet/IP and
DH-485 Networks
Introduction
This chapter describes how to set up communication from a Logix controller
to an SLC controller over an EtherNet/IP network.
For See
Hardware Configuration 10-2
Create a Remote 1756-ENBT Message in
RSLogix 5000
10-3
Configure the Message 10-4
IMPORTANT
The examples use SLC 5/03 modules to send DH-485
messages. In each case, the use of these devices is strictly
for example purposes and not an indication of restrictions
on the 1756-DH485 module.
