1 Publication 1756-UM532A-EN-P - May 2006
Chapter
9
Communicate to a SLC 5/03 Controller on a
DH-485 Network
Introduction
This chapter describes how to configure remote CIP communication from a
1756-L55 controller to an SLC 5/03 controller through DH+ and DH485
networks.
For See
Hardware Configuration 9-2
Create a Message in RSLogix 5000 9-3
Configure the Message 9-4
IMPORTANT
The examples use the 1756-DH485 module to initiate the
message to the SLC 5/03 module. In each case, the use of
these devices is strictly for example purposes and not an
indication of restrictions on the 1756-DH485 module.
