1 Publication 1756-UM532A-EN-P - May 2006
Chapter
8
Communicate from an SLC 5/05 Controller to
an SLC 5/03 Controller over an EtherNet/IP
Network
Introduction
This chapter describes the communications from an SLC 5/05 controller to an
SLC 5/03 controller over an EtherNet/IP network.
For See
Hardware Configuration 8-2
Create a Message in RSLogix 500 8-3
Configure the Message 8-4
Review the Multihop Feature in RSLogix 500 8-5
IMPORTANT
The examples use SLC 5/05 controllers to send DH-485
messages. In each case, the use of these devices is strictly
for example purposes and not an indication of restrictions
on the 1756-DH485 module.
