Communicate Between a PLC-5 Controller
and a Remote SLC 5/03 Controller over
Multiple DH-485 Networks
Introduction
This chapter describes how to set up the communications for a remote PLC-5
controller to send a message to a remote SLC 5/03 controller over multiple
DH-485 Networks.
For See
Hardware Configuration 7-4
Create a Message in RSLogix 5 7-4
Configure the Message 7-5
Create the Routing Table 7-3
IMPORTANT
The examples use SLC 5/03 modules to send DH-485
messages. In each case, the use of these devices is strictly
for example purposes and not an indication of restrictions
on the 1756-DH485 module.
