1 Publication 1756-UM532A-EN-P - May 2006
Chapter
6
Communicate Between SLC Controllers over
DH+ and DH485 Networks
Introduction
This chapter describes how to set up the message communications between
two SLC controllers.
For See
SLC 5/04 Controller Sends a Remote Message 6-2
Hardware Configuration 6-2
Create the Routing Table in RSLinx Software 6-3
Create a Message in RSLogix 500 6-6
Configure the Message 6-7
SLC 5/03 Controller Sends a Remote Message 6-8
Hardware Configuration 6-8
Create the Routing Table in RSLinx Software 6-9
Create a Remote Message in RSLogix 500 6-10
Configure the Message 6-11
IMPORTANT
The examples use SLC 5/03 and SLC 5/04 controllers to
send DH-485 messages. In each case, the use of these
devices is strictly for example purposes and not an
indication of restrictions on the 1756-DH485 module.
