5-2 Communicate from an SLC 5/03 Controller to a Logix Controller over a DH-485 Network
Hardware Configuration
In this hardware configuration, the communications are initiated by an SLC
5/03 controller. The message is sent to a 1756-DH485 module and the
1756-Lx controller is located in slot 11.
Communications Between an SLC 5/03 Controller and a 1756-DH485 Module
DH+/RIO
DH485
TERM
TE
T
A
A
A
A
B
B
B
COM
C
C
1756--L1 Controller
1756-DH485
SLC 5/03 Controller
DH485 network
communicating
through link
couplers.
44070
AIC+
AIC
