Publication 1756-UM532A-EN-P - May 2006

Use Data Highway 485 Network 3-11

Configuration Information

in DH-485 Messaging

When you are doing DH-485 messaging, you must first set up the

1756-DH485 module configuration. The following configuration information

is stored in the non-volatile (NVS) memory on your 1756-DH485 module

when you configure the module using RSLinx software.

• Any routing table that may be needed to send DH-485 messages

through the module. - This information must be applied to the module’s

configuration separately from other information. Use RSLinx to apply

the routing table.

For more information about routing tables, see the section Use RSLinx

Software to Create a Routing Table in Chapter 4.

• Controller slot assignment for each DH-485 channel.

Refer to Set the Controller Slot on page 4-8 for more information on

local messaging.

• The node number of the module.

IMPORTANT

If you restore defaults with RSLinx software, the slot

number will remain the 1756-DH485 module’s non-volatile

memory, but the routing table and the controller slot for

both DH-485 channels will be reset.
