Publication 1756-UM532A-EN-P - May 2006

Use Data Highway 485 Network 3-9

The following table lists what the controllers are capable of on DH-485.

Controllers and the Types of Messaging Capable on a DH-485 Network

Controller

Messaging

Respond to

Local DH-485

Initiate Local

DH-485

Respond to

Remote

DH-485

Initiate

Remote

DH-485

MicroLogix 1000 Yes Yes Yes No

MicroLogix 1100 Yes Yes Yes Yes

MicroLogix 1200 Yes Yes Yes Yes

MicroLogix 1500 Yes Yes Yes Yes

SLC 500 fixed Yes No No No

SLC 5/01 Yes No No No

SLC 5/02 Yes Yes No No

SLC 5/03 Yes Yes Yes Yes

SLC 5/04 Yes Yes Yes Yes

SLC 5/05 Yes Yes Yes Yes

Logix Yes Yes

(1)

Yes for CIP remote messaging only .

Yes
