3-2 Use Data Highway 485 Network

Link Design

When you design your DH-485 link, you should use good design practices,

including laying out the link before installation. We also recommend you

consider the following when designing your DH-485 link:

• All performance requirements

• Maintenance

• Possible future changes to the link

Use a Belden 9842 or a Belden 3106A cable to connect your module to

DH-485. Only connect a DH-485 network using a daisy-chain configuration.

If you need to know how to install a DH-485 network, refer to publication

1747-UM011, SLC 500 Modular Hardware Style User Manual.

Two Methods of

Communication Over a

DH-485 Network

The 1756-DH485 module acts as a bridge for two methods of communication.

These methods are:

• DH-485 Messaging

• Common Industrial Protocol (CIP) Messaging

The table Types of Communication on the 1756-DH485 Module lists the

devices that support each communication method.

Types of Communication on the 1756-DH485 Module

Type of Communication Devices and Softw are Support

DH-485 messaging SLC-500 -5/05, 5/04, 5/03, 5/02, 5/01, MicroLogix

Logix controllers

RSLinx and RSLogix 500 software

Common Industrial Protocol

(CIP) messaging

Logix controllers

RSLogix 5000 and RSLinx software
