Publication 1756-UM532A-EN-P - May 2006

1756-DH485 Module Overview 1-7

Remote Messaging

The configuration of remote messaging is similar to data highway remote I/O

(DHRIO). It is achieved through routing table functions and module

configuration. The multi-hop functionality is available in RSLogix 5 and 500

(version 6.3 or later)

Remote Upload and Download

You can bridge EtherNet/IP and ControlNet networks to a DH-485 network

using the 1756-DH485 module

You can upload and download:

• all MicroLogix and SLC 500 controllers on DH-485 from NetLinx

network by using RSLinx Classic software.

• PanelView Standard terminals on DH-485 from NetLinx network by

using RSLinx Classic.

Logix controllers message via a NetLinx network through a ControlLogix

gateway to the DH-485 network to all MicroLogix and SLC 5/03 (and above)

controllers on DH-485 network. RSLinx Classic software on the DH-485

network can browse through the ControlLogix gateway to any device on a

NetLinx network.

IMPORTANT

Logix controllers on a NetLinx network will not be able to

initiate messages through the ControlLogix gateway to the

DH-485 network to fixed SLC 500, SLC 5/01, or SLC

5/02 controllers on a DH-485 network.
