1-6 1756-DH485 Module Overview

The second example shows how you can connect or migrate a legacy system to

a new installation with RSLogix software.

• Connect multiple DH-485 networks together for inter-network

communications.

• Message between SLC 5/03 controllers.

• Provide connection to other NetLinx networks.

• Access through a single point and download to an SLC controller,

MicroLogix controller, and Panelview display.

• Allow communications between legacy and ControlLogix systems for

high integration of control systems (except for fixed SLC controllers).

• Phase SLC systems into ControlLogix architecture by using a migration

tool.

Connect or Migrate a Legacy System to a New Insta llation

EXTERNAL

TERM

44136

1756-DH485

AIC+ Link Coupler

AIC Link Coupler

PanelView Display

SLC 5/03 Controller

1756-ENBT Module

AIC+ Link Coupler

AIC Link Coupler

SLC 5/03 Controller

MicroLogix

DH485 Network

ControlLogix Controller

Computer with RSlogix 500

and RSLogix 5000 Software

AIC Link Coupler

AIC+
