22 ControlLogix ControlNet Interface Module
Publication
1756-IN607A-EN-P - February 2008
Status Indicators
Module
1756-CN2R
Module
COAX
B
A
OK
B
A
COAX
A
OK
A
1756-CN2
Module Status Display -
See page 23
Module Status LED
Indicator -
See page 23
ControlNet Channel Status Indicators -
See page 29
The modules have these status indicators.
