ControlLogix ControlNet Interface Module 19
Publication
1756-IN607A-EN-P - February 2008
Install the EDS File
The EDS file can be uploaded directly from the module. This feature
lets you register the EDS file for your module from within RSLinx
software by following the steps listed below.
1. Open RSLinx software, and browse for the module.
2. Right-click the module and select Upload EDS file from device.
The Upload EDS wizard opens.
3. Complete the EDS wizard to register the EDS file.
The EDS file can also be downloaded from
www.ab.com/networks/eds.html
and installed with the RSLinx EDS
Hardware Installation Tool.
