Digital Output Terminals
Terminals accommodate wires up to 1.5 mm
2
(16 AWG). See the terminal torque specifications
on page 17
. Digital outputs are connected to these terminals.
For connection of a load, the reference pole L- of the corresponding channel group must be used
(2-pole connection). Although L- at terminals 1 and 6 and at 7 and 12 is connected internally to
L- on the power supply input, it is strictly recommended to use 1 and 6 for outputs 1…4 only and
7 and 12 for outputs 5… 8 only. EMC testing was performed in this manner.
Terminal Number Designation Function Current
1 L- Reference pole —
2 1 Digital output 1 0.5 A
3 2 Digital output 2 0.5 A
4 3 Digital output 3 0.5 A
5 4 Digital output 4 (for increased load) 2.0 A
6 L- Reference pole —
7 L- Reference pole —
8 5 Digital output 5 0.5 A
9 6 Digital output 6 0.5 A
10 7 Digital output 7 0.5 A
11 8 Digital output 8 (for increased load) 2.0 A
12 L- Reference pole —
123456
1234
1L- L-DO 2
(2A)
34
56
789101112
78910
5L- L-DO 6
(2A)
7 8
11 12
