Publication 1734-UM016A-EN-P - October 2010
Introduction 3
Supported Connection Points for Connection Styles
Connection Configuration
Connection Point
Consumed
Connection Point
Produced
Connection Point
Exclusive Owner 102 100 101
Listen-only 102 191 101
Input-only 102 190 101
Owning with no status header 102 100 103
Listen-only with no status header 102 191 103
Input-only with no status header 102 190 103
