68 1734/1738 I/O Module Assembly Information
12 Sensor Cycles (Low Byte)
13 Sensor Cycles (High Byte)
14 SSI Word Filter Control
15 Alignment (reserved = 0)
16 Comparator 1 Value [Low Byte]
17 Comparator 1 Value [1]
18 Comparator 1 Value [2]
19 Comparator 1 Value [High Byte]
20 Comparator 2 Value [Low Byte]
21 Comparator 2 Value [1]
22 Comparator 2 Value [2]
23 Comparator 2 Value [High Byte]
24 Comparator 1 Control
25 Comparator 2 Control
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Present SSI Word [Low Byte]
1 Present SSI Word [1]
2 Present SSI Word [2]
3 Present SSI Word [High Byte]
4 Latched SSI Word [Low Byte]
5 Latched SSI Word [1]
6 Latched SSI Word [2]
7 Latched SSI Word [High Byte]
8 Module Status (Low Byte)
9 Module Status (High Byte)
Consumed Output Data Assembly 102
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Master Ack Byte Output Control
1 Reserved = 0
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
