1734/1738 I/O Module Assembly Information 67
Synchronous Serial Interface Modules
Use the tables shown below for the following modules:
• 1734-SSI or 1738-SSIM12
43 Cold Junction Enable Chan 1
44 Cold Junction Offset Chan 1 (Low Byte)
45 Cold Junction Offset Chan 1 (High Byte)
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Data (Low Byte)
1 Channel 0 Data (High Byte)
2 Channel 1 Data (Low Byte)
3 Channel 1 Data (High Byte)
4 Channel 0 Status
5 Channel 1 Status
6 CJC Data (Low Byte)
7 CJC Data (High Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0Run
1 Gray/Binary
2 SSI Word Length
3 Data Rate
4 Gray to Binary Conversion
5 Standardization
6 SSI Word Delay Time (Low Byte)
7 SSI Word Delay Time (High Byte)
8 Trailing bits
9 Latch Input Control
10 Sensor Resolution (Low Byte)
11 Sensor Resolution (High Byte)
Configuration Assembly Instance 103
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
