Assembly Connections for POINT I/O and ArmorPOINT I/O EtherNet/IP Adapters User Manual

Publication 1734-UM016A-EN-P - October 2010
1734/1738 I/O Module Assembly Information 65
Two-channel Thermocouple Input Modules
Use the tables shown below for the following modules:
• 1734-IR2I or 1738-IR2IM12
28 Low Low Alarm Channel 1 (Low Byte)
29 Low Low Alarm Channel 1 (High Byte)
30 High High Alarm Channel 1 (Low Byte)
31 High High Alarm Channel 1 (High Byte)
32 Alarm Latch Channel 1
33 Alarm Disable Channel 1
34 Sensor Type Channel 1
35 Temperature Units Channel 1
36 Notch Filter
37 Alignment (reserved = 0)
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Data (Low Byte)
1 Channel 0 Data (High Byte)
2 Channel 1 Data (Low Byte)
3 Channel 1 Data (High Byte)
4 Channel 0 Status
5 Channel 1 Status
Configuration Assembly Instance 103
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Cold Junction Notch Filter
1 Cold Junction Produced
2 Low Engineering Channel 0 (Low Byte)
3 Low Engineering Channel 0 (High Byte)
4 High Engineering Channel 0 (Low Byte)
5 High Engineering Channel 0 (High Byte)
6 Alarm Disable Channel 0
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
