Publication 1734-UM016A-EN-P - October 2010
64 1734/1738 I/O Module Assembly Information
Two-channel RTD Input Modules
Use the tables shown below for the following modules:
• 1734-IR2
• 1734-IR2E or 1738-IR2M12
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Low Engineering Channel 0 (Low Byte)
1 Low Engineering Channel 0 (High Byte)
2 High Engineering Channel 0 (Low Byte)
3 High Engineering Channel 0 (High Byte)
4 Digital Filter Channel 0 (Low Byte)
5 Digital Filter Channel 0 (High Byte)
6 Low Alarm Channel 0 (Low Byte)
7 Low Alarm Channel 0 (High Byte)
8 High Alarm Channel 0 (Low Byte)
9 High Alarm Channel 0 (High Byte)
10 Low Low Alarm Channel 0 (Low Byte)
11 Low Low Alarm Channel 0 (High Byte)
12 High High Alarm Channel 0 (Low Byte)
13 High High Alarm Channel 0 (High Byte)
14 Alarm Latch Channel 0
15 Alarm Disable Channel 0
16 Sensor Type Channel 0
17 Temperature Units Channel 0
18 Low Engineering Channel 1 (Low Byte)
19 Low Engineering Channel 1 (High Byte)
20 High Engineering Channel 1 (Low Byte)
21 High Engineering Channel 1 (High Byte)
22 Digital Filter Channel 1 (Low Byte)
23 Digital Filter Channel 1 (High Byte)
24 Low Alarm Channel 1 (Low Byte)
25 Low Alarm Channel 1 (High Byte)
26 High Alarm Channel 1 (Low Byte)
27 High Alarm Channel 1 (High Byte)
