1734/1738 I/O Module Assembly Information 63
56 Idle Data Channel 3 (Low Byte)
57 Idle Data Channel 3 (High Byte)
58 Low Engineering Channel 3 (Low Byte)
59 Low Engineering Channel 3 (High Byte)
60 High Engineering Channel 3 (Low Byte)
61 High Engineering Channel 3 (High Byte)
62 Low Clamp Channel 3 (Low Byte)
63 Low Clamp Channel 3 (High Byte)
64 High Clamp Channel 3 (Low Byte)
65 High Clamp Channel 3 (High Byte)
66 Range Channel 3
67 Fault Action Channel 3
68 Idle Action Channel 3
69 Alarm Latch Channel 3
70 Alarm Disable Channel 3
71 Alignment (reserved = 0)
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Status
1 Channel 1 Status
2 Channel 2 Status
3 Channel 3 Status
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Data (Low Byte)
1 Channel 0 Data (High Byte)
2 Channel 1 Data (Low Byte)
3 Channel 1 Data (High Byte)
4 Channel 2 Data (Low Byte)
5 Channel 2 Data (High Byte)
6 Channel 3 Data (Low Byte)
7 Channel 3 Data (High Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
