62 1734/1738 I/O Module Assembly Information
20 Idle Data Channel 1 (Low Byte)
21 Idle Data Channel 1 (High Byte)
22 Low Engineering Channel 1 (Low Byte)
23 Low Engineering Channel 1 (High Byte)
24 High Engineering Channel 1 (Low Byte)
25 High Engineering Channel 1 (High Byte)
26 Low Clamp Channel 1 (Low Byte)
27 Low Clamp Channel 1 (High Byte)
28 High Clamp Channel 1 (Low Byte)
29 High Clamp Channel 1 (High Byte)
30 Range Channel 1
31 Fault Action Channel 1
32 Idle Action Channel 1
33 Alarm Latch Channel 1
34 Alarm Disable Channel 1
35 Alignment (reserved = 0)
36 Fault Data Channel 2 (Low Byte)
37 Fault Data Channel 2 (High Byte)
38 Idle Data Channel 2 (Low Byte)
39 Idle Data Channel 2 (High Byte)
40 Low Engineering Channel 2 (Low Byte)
41 Low Engineering Channel 2 (High Byte)
42 High Engineering Channel 2 (Low Byte)
43 High Engineering Channel 2 (High Byte)
44 Low Clamp Channel 2 (Low Byte)
45 Low Clamp Channel 2 (High Byte)
46 High Clamp Channel 2 (Low Byte)
47 High Clamp Channel 2 (High Byte)
48 Range Channel 2
49 Fault Action Channel 2
50 Idle Action Channel 2
51 Alarm Latch Channel 2
52 Alarm Disable Channel 2
53 Alignment (reserved = 0)
54 Fault Data Channel 3 (Low Byte)
55 Fault Data Channel 3 (High Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
