1734/1738 I/O Module Assembly Information 61
Four-channel Analog Output Modules
Use the tables shown below for the following modules:
• 1734-OE4C
• 1738-OE4CM12 or 1738-OE4VM12
Consumed Output Data Assembly 102
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Data (Low Byte)
1 Channel 0 Data (High Byte)
2 Channel 1 Data (Low Byte)
3 Channel 1 Data (High Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Fault Data Channel 0 (Low Byte)
1 Fault Data Channel 0 (High Byte)
2 Idle Data Channel 0 (Low Byte)
3 Idle Data Channel 0 (High Byte)
4 Low Engineering Channel 0 (Low Byte)
5 Low Engineering Channel 0 (High Byte)
6 High Engineering Channel 0 (Low Byte)
7 High Engineering Channel 0 (High Byte)
8 Low Clamp Channel 0 (Low Byte)
9 Low Clamp Channel 0 (High Byte)
10 High Clamp Channel 0 (Low Byte)
11 High Clamp Channel 0 (High Byte)
12 Range Channel 0
13 Fault Action Channel 0
14 Idle Action Channel 0
15 Alarm Latch Channel 0
16 Alarm Disable Channel 0
17 Alignment (reserved = 0)
18 Fault Data Channel 1 (Low Byte)
19 Fault Data Channel 1 (High Byte)
