60 1734/1738 I/O Module Assembly Information
7 High Engineering Channel 0 (High Byte)
8 Low Clamp Channel 0 (Low Byte)
9 Low Clamp Channel 0 (High Byte)
10 High Clamp Channel 0 (Low Byte)
11 High Clamp Channel 0 (High Byte)
12 Range Channel 0
13 Fault Action Channel 0
14 Idle Action Channel 0
15 Alarm Latch Channel 0
16 Alarm Disable Channel 0
17 Alignment (reserved = 0)
18 Fault Data Channel 1 (Low Byte)
19 Fault Data Channel 1 (High Byte)
20 Idle Data Channel 1 (Low Byte)
21 Idle Data Channel 1 (High Byte)
22 Low Engineering Channel 1 (Low Byte)
23 Low Engineering Channel 1 (High Byte)
24 High Engineering Channel 1 (Low Byte)
25 High Engineering Channel 1 (High Byte)
26 Low Clamp Channel 1 (Low Byte)
27 Low Clamp Channel 1 (High Byte)
28 High Clamp Channel 1 (Low Byte)
29 High Clamp Channel 1 (High Byte)
30 Range Channel 1
31 Fault Action Channel 1
32 Idle Action Channel 1
33 Alarm Latch Channel 1
34 Alarm Disable Channel 1
35 Alignment (reserved = 0)
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Status
1 Channel 1 Status
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
