Assembly Connections for POINT I/O and ArmorPOINT I/O EtherNet/IP Adapters User Manual

Publication 1734-UM016A-EN-P - October 2010
1734/1738 I/O Module Assembly Information 59
Two-channel Analog Output Modules
Use the tables shown below for the following modules:
• 1734-OE2C
• 1734-OE2V
• 1738-OE2CM12 or 1738-OE2VM12
8 Channel 4 Data (Low Byte)
9 Channel 4 Data (High Byte)
10 Channel 5 Data (Low Byte)
11 Channel 5 Data (High Byte)
12 Channel 6 Data (Low Byte)
13 Channel 6 Data (High Byte)
14 Channel 7 Data (Low Byte)
15 Channel 7 Data (High Byte)
16 Channel 0 Status
17 Channel 1 Status
18 Channel 2 Status
19 Channel 3 Status
20 Channel 4 Status
21 Channel 5 Status
22 Channel 6 Status
23 Channel 7 Status
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Fault Data Channel 0 (Low Byte)
1 Fault Data Channel 0 (High Byte)
2 Idle Data Channel 0 (Low Byte)
3 Idle Data Channel 0 (High Byte)
4 Low Engineering Channel 0 (Low Byte)
5 Low Engineering Channel 0 (High Byte)
6 High Engineering Channel 0 (Low Byte)
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
