1734/1738 I/O Module Assembly Information 57
84 High High Alarm Channel 4 (Low Byte)
85 High High Alarm Channel 4 (High Byte)
86 Range Channel 4
87 Alarm Latch Channel 4
88 Alarm Disable Channel 4
89 Alignment (reserved = 0)
90 Low Engineering Channel 5 (Low Byte)
91 Low Engineering Channel 5 (High Byte)
92 High Engineering Channel 5 (Low Byte)
93 High Engineering Channel 5 (High Byte)
94 Digital Filter Channel 5 (Low Byte)
95 Digital Filter Channel 5 (High Byte)
96 Low Alarm Channel 5 (Low Byte)
97 Low Alarm Channel 5 (High Byte)
98 High Alarm Channel 5 (Low Byte)
99 High Alarm Channel 5 (High Byte)
100 Low Low Alarm Channel 5 (Low Byte)
101 Low Low Alarm Channel 5 (High Byte)
102 High High Alarm Channel 5 (Low Byte)
103 High High Alarm Channel 5 (High Byte)
104 Range Channel 5
105 Alarm Latch Channel 5
106 Alarm Disable Channel 5
107 Alignment (reserved = 0)
108 Low Engineering Channel 6 (Low Byte)
109 Low Engineering Channel 6 (High Byte)
110 High Engineering Channel 6 (Low Byte)
111 High Engineering Channel 6 (High Byte)
112 Digital Filter Channel 6 (Low Byte)
113 Digital Filter Channel 6 (High Byte)
114 Low Alarm Channel 6 (Low Byte)
115 Low Alarm Channel 6 (High Byte)
116 High Alarm Channel 6 (Low Byte)
117 High Alarm Channel 6 (High Byte)
118 Low Low Alarm Channel 6 (Low Byte)
119 Low Low Alarm Channel 6 (High Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
