56 1734/1738 I/O Module Assembly Information
48 High High Alarm Channel 2 (Low Byte)
49 High High Alarm Channel 2 (High Byte)
50 Range Channel 2
51 Alarm Latch Channel 2
52 Alarm Disable Channel 2
53 Alignment (reserved = 0)
54 Low Engineering Channel 3 (Low Byte)
55 Low Engineering Channel 3 (High Byte)
56 High Engineering Channel 3 (Low Byte)
57 High Engineering Channel 3 (High Byte)
58 Digital Filter Channel 3 (Low Byte)
59 Digital Filter Channel 3 (High Byte)
60 Low Alarm Channel 3 (Low Byte)
61 Low Alarm Channel 3 (High Byte)
62 High Alarm Channel 3 (Low Byte)
63 High Alarm Channel 3 (High Byte)
64 Low Low Alarm Channel 3 (Low Byte)
65 Low Low Alarm Channel 3 (High Byte)
66 High High Alarm Channel 3 (Low Byte)
67 High High Alarm Channel 3 (High Byte)
68 Range Channel 3
69 Alarm Latch Channel 3
70 Alarm Disable Channel 3
71 Alignment (reserved = 0)
72 Low Engineering Channel 4 (Low Byte)
73 Low Engineering Channel 4 (High Byte)
74 High Engineering Channel 4 (Low Byte)
75 High Engineering Channel 4 (High Byte)
76 Digital Filter Channel 4 (Low Byte)
77 Digital Filter Channel 4 (High Byte)
78 Low Alarm Channel 4 (Low Byte)
79 Low Alarm Channel 4 (High Byte)
80 High Alarm Channel 4 (Low Byte)
81 High Alarm Channel 4 (High Byte)
82 Low Low Alarm Channel 4 (Low Byte)
83 Low Low Alarm Channel 4 (High Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
