54 1734/1738 I/O Module Assembly Information
Eight-channel Analog Input Modules
Use the tables shown below for the following modules:
• 1734-IE8C
• 1734-IE8V
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Data (Low Byte)
1 Channel 0 Data (High Byte)
2 Channel 1 Data (Low Byte)
3 Channel 1 Data (High Byte)
4 Channel 2 Data (Low Byte)
5 Channel 2 Data (High Byte)
6 Channel 3 Data (Low Byte)
7 Channel 3 Data (High Byte)
8 Channel 0 Status
9 Channel 1 Status
10 Channel 2 Status
11 Channel 3 Status
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Low Engineering Channel 0 (Low Byte)
1 Low Engineering Channel 0 (High Byte)
2 High Engineering Channel 0 (Low Byte)
3 High Engineering Channel 0 (High Byte)
4 Digital Filter Channel 0 (Low Byte)
5 Digital Filter Channel 0 (High Byte)
6 Low Alarm Channel 0 (Low Byte)
7 Low Alarm Channel 0 (High Byte)
8 High Alarm Channel 0 (Low Byte)
9 High Alarm Channel 0 (High Byte)
10 Low Low Alarm Channel 0 (Low Byte)
11 Low Low Alarm Channel 0 (High Byte)
