Assembly Connections for POINT I/O and ArmorPOINT I/O EtherNet/IP Adapters User Manual

Publication 1734-UM016A-EN-P - October 2010
52 1734/1738 I/O Module Assembly Information
5 Digital Filter Channel 0 (High Byte)
6 Low Alarm Channel 0 (Low Byte)
7 Low Alarm Channel 0 (High Byte)
8 High Alarm Channel 0 (Low Byte)
9 High Alarm Channel 0 (High Byte)
10 Low Low Alarm Channel 0 (Low Byte)
11 Low Low Alarm Channel 0 (High Byte)
12 High High Alarm Channel 0 (Low Byte)
13 High High Alarm Channel 0 (High Byte)
14 Range Channel 0
15 Alarm Latch Channel 0
16 Alarm Disable Channel 0
17 Alignment (reserved = 0)
18 Low Engineering Channel 1 (Low Byte)
19 Low Engineering Channel 1 (High Byte)
20 High Engineering Channel 1 (Low Byte)
21 High Engineering Channel 1 (High Byte)
22 Digital Filter Channel 1 (Low Byte)
23 Digital Filter Channel 1 (High Byte)
24 Low Alarm Channel 1 (Low Byte)
25 Low Alarm Channel 1 (High Byte)
26 High Alarm Channel 1 (Low Byte)
27 High Alarm Channel 1 (High Byte)
28 Low Low Alarm Channel 1 (Low Byte)
29 Low Low Alarm Channel 1 (High Byte)
30 High High Alarm Channel 1 (Low Byte)
31 High High Alarm Channel 1 (High Byte)
32 Range Channel 1
33 Alarm Latch Channel 1
34 Alarm Disable Channel 1
35 Alignment (reserved = 0)
36 Low Engineering Channel 2 (Low Byte)
37 Low Engineering Channel 2 (High Byte)
38 High Engineering Channel 2 (Low Byte)
39 High Engineering Channel 2 (High Byte)
40 Digital Filter Channel 2 (Low Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
