Assembly Connections for POINT I/O and ArmorPOINT I/O EtherNet/IP Adapters User Manual

Publication 1734-UM016A-EN-P - October 2010
1734/1738 I/O Module Assembly Information 51
Four-channel Analog Input Modules
Use the tables shown below for the following modules:
• 1734-IE4C
• 1738-IE4CM12 or 1738-IE4VM12
27 High Alarm Channel 1 (High Byte)
28 Low Low Alarm Channel 1 (Low Byte)
29 Low Low Alarm Channel 1 (High Byte)
30 High High Alarm Channel 1 (Low Byte)
31 High High Alarm Channel 1 (High Byte)
32 Range Channel 1
33 Alarm Latch Channel 1
34 Alarm Disable Channel 1
35 Notch Filter
36 Update Rate (Low Byte)
37 Update Rate (High Byte)
Produced Input Data Assembly 101
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Channel 0 Data (Low Byte)
1 Channel 0 Data (High Byte)
2 Channel 1 Data (Low Byte)
3 Channel 1 Data (High Byte)
4 Channel 0 Status
5 Channel 1 Status
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Low Engineering Channel 0 (Low Byte)
1 Low Engineering Channel 0 (High Byte)
2 High Engineering Channel 0 (Low Byte)
3 High Engineering Channel 0 (High Byte)
4 Digital Filter Channel 0 (Low Byte)
Configuration Assembly Instance 123
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
