44 1734/1738 I/O Module Assembly Information
This POINT I/O input module produces 2 or 3 bytes of input data based on
which produced assembly is selected. The default assembly instance 101 is 3
bytes. This module does not consume I/O data.
Sixteen-channel Discrete Output Modules
Use the table shown below for the following modules:
• 1738-OB16E19M23
• 1738-OB16E25DS
• 1738-OB16EM12
Configuration Assembly Instance 103
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Input Off to On Filter Low Byte
1 Input Off to On Filter High Byte
2 Input On to Off Filter Low Byte
3 Input On to Off Filter High Byte
4 Produced Assembly
5 Reserved = 0
Produced Diagnostic Input Data Assembly Instance 101
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Ch 7 Ch 6 Ch 5 Ch 4 Ch 3 Ch 2 Ch 1 Ch 0
1 Ch 15 Ch 14 Ch 13 Ch 12 Ch 11 Ch 10 Ch 9 Ch 8
2 Reserved Fault LED
State
SSV Fault
12…15
SSV Fault
8…11
SSV Fault
4…7
SSV Fault
0…3
Produced Input Data Assembly Instance 5
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Ch 7 Ch 6 Ch 5 Ch 4 Ch 3 Ch 2 Ch 1 Ch 0
1 Ch 15 Ch 14 Ch 13 Ch 12 Ch 11 Ch 10 Ch 9 Ch 8
Configuration Assembly Instance 123
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Enable
Latched Faults
Idle Value Idle Action Fault Value Fault Action
1 Reserved = 0
