1734/1738 I/O Module Assembly Information 43
Two-channel Relay and AC Output Modules
All two-channel relay and AC output modules use the same Consumed I/O
assembly. There are no Produced or Configuration assemblies for these
modules. Use the table shown below for the following modules:
• 1734-OW2
• 1734-OX2
• 1734-OA2 or 1738-OA2M12AC3
Four-channel Relay and AC Output Modules
All four channel relay and AC output modules use the same Consumed I/O
assembly. There are no Produced or Configuration assemblies for these
modules. Use the table shown below for the following modules:
• 1734-OW4
• 1734-OW4M12 or 1738-OW4M12AC
• 1734-OA4
Sixteen-channel Discrete Diagnostic Input Modules
Use the table shown below for the following modules:
• 1738-IB16DM12
Consumed Output Data Assembly 32
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Reserved Ch 1 Ch 0
Consumed Output Data Assembly 32
Byte Bit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Reserved Ch 3 Ch 2 Ch 1 Ch 0
