Publication 1734-UM016A-EN-P - October 2010
1734/1738 I/O Module Assembly Information 41
Eight-channel Discrete Output Modules
Use the tables shown below for the following modules:
• 1734-OB8 or 1738-OB8
Four-channel Discrete Diagnostic Input Modules
Use the tables shown below for the following modules:
• 1734-IB4D or 1738-IB4DM12
Configuration Assembly Instance 123
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Fault State 7 Fault State 6 Fault State 5 Fault State 4 Fault State 3 Fault State 2 Fault State 1 Fault State 0
1 Fault Value 7 Fault Value 6 Fault Value 5 Fault Value 4 Fault Value 3 Fault Value 2 Fault Value 1 Fault Value 0
2 Idle State 7 Idle State 6 Idle State 5 Idle State 4 Idle State 3 Idle State 2 Idle State 1 Idle State 0
3 Idle Value 7 Idle Value 6 Idle Value 5 Idle Value 4 Idle Value 3 Idle Value 2 Idle Value 1 Idle Value 0
4 Enable No
Load 7
Enable No
Load 6
Enable No
Load 5
Enable No
Load 4
Enable No
Load 3
Enable No
Load 2
Enable No
Load 1
Enable No
Load 0
5 Reset Mode 7 Reset Mode 6 Reset Mode 5 Reset Mode 4 Reset Mode 3 Reset Mode 2 Reset mode 1 Reset mode 0
6 Enable
Latched
Alarms 7
Enable
Latched
Alarms 6
Enable
Latched
Alarms 5
Enable
Latched
Alarms 4
Enable
Latched
Alarms 3
Enable
Latched
Alarms 2
Enable
Latched
Alarms 1
Enable
Latched
Alarms 0
7 Pad
Produced Input Data Assembly 44
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Reserved
Consumed Output Data Assembly 34
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 Ch 7 Ch 6 Ch 5 Ch 4 Ch 3 Ch 2 Ch 1 Ch 0
