38 1734/1738 I/O Module Assembly Information
Two-channel Discrete Output Modules
Use the tables shown below for the following modules:
• 1734-OB2 or 1738-OB2
Four-channel Discrete Output Modules with Status
All four-channel "enhanced" discrete output modules use the same
configuration and I/O assemblies. Use the tables shown below for the
following modules:
• 1734-OB4E or 1738-OB4E
• 1734-OV4E or 1738-0V4E
Configuration Assembly Instance 123
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Fault State 1 Fault State 0
1 Reserved Fault Value 1 Fault Value 0
2 Reserved Idle State 1 Idle State 0
3 Reserved Idle Value 1 Idle Value 0
4 Reserved (Set to 0)
5 Reserved (Set to 0)
6 Reserved (Set to 0)
7 Pad
Produced Input Data Assembly 42
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved
Consumed Output Data Assembly 32
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Ch 1 Ch 0
