36 1734/1738 I/O Module Assembly Information
• 1734-IB8 or 1738-IB8
• 1734-IV8 or 1738-IV8
Configuration Assembly Instance 103
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Input 0 Off to On Filter Low Byte
1 Input 0 Off to On Filter High Byte
2 Input 0 On to Off Filter Low Byte
3 Input 0 On to Off Filter High Byte
4 Input 1 Off to On Filter Low Byte
5 Input 1 Off to On Filter High Byte
6 Input 1 On to Off Filter Low Byte
7 Input 1 On to Off Filter High Byte
8 Input 2 Off to On Filter Low Byte
9 Input 2 Off to On Filter High Byte
10 Input 2 On to Off Filter Low Byte
11 Input 2 On to Off Filter High Byte
12 Input 3 Off to On Filter Low Byte
13 Input 3 Off to On Filter High Byte
14 Input 3 On to Off Filter Low Byte
15 Input 3 On to Off Filter High Byte
16 Input 4 Off to On Filter Low Byte
17 Input 4 Off to On Filter High Byte
18 Input 4 On to Off Filter Low Byte
19 Input 4 On to Off Filter High Byte
20 Input 5 Off to On Filter Low Byte
21 Input 5 Off to On Filter High Byte
22 Input 5 On to Off Filter Low Byte
23 Input 5 On to Off Filter High Byte
24 Input 6 Off to On Filter Low Byte
25 Input 6 Off to On Filter High Byte
26 Input 6 On to Off Filter Low Byte
27 Input 6 On to Off Filter High Byte
28 Input 7 Off to On Filter Low Byte
29 Input 7 Off to On Filter High Byte
30 Input 7 On to Off Filter Low Byte
31 Input 7 On to Off Filter High Byte
